| Call sign |
YCRY2 |
Communication & Navigation |
| Official No. |
JJR-111020 |
Inmarsat F33 |
Tel +871.765.084.710 |
| IMO No |
9038476 |
Fax +871.765.084.712 |
| Class |
KR |
Iridium Mobile |
+8816.2242.4077 |
| Flag |
Indonesia |
E-mail: gdn_garda@sea-one.com |
| Built year |
29 MAY 1992 |
Inmarsat C |
JRC/JUE-85-435307112 |
| Where Built |
ODO Shipbuilding
JAPAN
á³Ú¦ðãàÏôÑÍï(ñ») |
MMSI |
353071000 |
| LRIT |
TT3010 |
| GRT |
610 |
| NRT |
183 |
AIS |
JRC/JHS-180 |
| LOA (m) |
49.61 |
NAVTEX |
JRC/NCR-300A |
| LPP (m) |
44.22 |
VHF Radio |
JRC/JHS 31 /32A |
| Breath (m) |
9.0 |
VHF Portable |
JRC/JHS-7 |
| Depth (m) |
5.92 |
Echo Sounder |
JRC/JFV-130A |
| Draft (m) |
3.73 |
DGPS |
VERIPOS HF (SBAS) 0.3 m |
| Main Engine |
YANMAR |
GPS |
JRC/GP-500M2 |
| Engine Model |
Z280-EN,
650/212 RPM |
Starlink Invictor210 |
| BHP |
1800 (1323KW) |
Radar |
JRC/JMA-6503-9(CA)
21” , 50kW, 120nm, ARFA |
Propulsion
|
CPP, 4 blades
CPC65A/80RN-1,
Dia 2800mm |
JMA 650-7
21:, 50kW, 120nm, ARFA
Total 2 units |
| Bow Thruster |
2.3Ton (140KW)
TCA-30MA, CPP |
Auto Pilot |
TOKYO KEIKI
PR-2504 HTL |
| Speed |
14/12 knots |
Gyro Compass |
TOKYO KEIKI (TG-5000) |
| Generator |
Taiyo, TWY 350-6
350KVA, AC225V
2 units |
GPS Compass |
Furuno SC50, 1 unit
Hemisphere V100, 1 unit |
| Aux Engine |
Yanmar S165L
DN420PSx1200 RPM |
GPS Plotter |
Samyoung Navis 3800 |
| Bollard Pull |
24 Metric Ton |
Weather Fax |
FURUNO |
| Accommodation |
Crew 11+Others 13
Total 24 persons |
NAV Computer |
3 units (Industrial Model) |
| FO/LO tank |
FO 238.6 CBM
LO 12.9 CBM |
Weather Sensor |
| Fresh Water |
48.1 ton |
Barometer |
YANAGI |
RO Desalinator
(HR-10N) |
5 ton/day
1 units |
Wind Speed |
FW 200 |
| Endurance |
50 days
(Transit40+Work10)
8000 nm |
Doppler Log |
3 sensors, 1 system |
| Echo sounder |
KCS 001 |
| Winch |
Drum winch 6 ton, 80m/min, Hydraulic x 2 units
Wire Spooling 22mm, 1000 meters x 2 drums
Net winch 6 ton x 1 unit on main winch
Total 18 ton |
Stern upper winch, Hydraulic 7 ton x 1 unit, 40m/min
Wire Spooling 24mm, 50 meters |
| Wire tension meter (Tension/Speed/Length/GPS Position) |
| Tug winch |
2 units, Hydraulic, Line pull 3 ton, 40m/min, 16mm x 50 m |
| Windlass |
4.2 ton x 12m/min |
